TOOL-HOLDER SD[**]
OTHERS FOR SD/SX
![TOOL-HOLDER SD[**]](res/chanp/20220326/472570554df8bbac.png)
| 型号 | d0 | d1 | lg | g | l1 | l2 |
|---|---|---|---|---|---|---|
| SDA 4 060 07 | 4 | 7 | 60 | M5 | ||
| SDA 4 060 08 | 4 | 8 | 60 | M5 | 27 | 5 |
| SDA 4 060 10 | 4 | 40 | 60 | M5 | 27 | 5 |
| SDA 4 060 12 | 4 | 12 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 12.7 | 4 | 12.7 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 14 | 4 | 14 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 16 | 4 | 16 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 18 | 4 | 18 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 19.05 | 4 | 19.05 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 20 | 4 | 20 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 22 | 4 | 22 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 25 | 4 | 25 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 25.40 | 4 | 25.4 | 60 | R 1/8 | 27 | 5 |
| SDA 4 060 28 | 4 | 28 | 60 | R 1/8 | 27 | 5 |
| SDA 4 100 08 | 4 | 8 | 100 | R 1/8 | 27 | 5 |
| SDA 4 100 10 | 4 | 10 | 100 | R 1/8 | 27 | 5 |
| SDA 4 120 12 | 4 | 12 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 12.7 | 4 | 12.7 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 14 | 4 | 14 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 16 | 4 | 16 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 18 | 4 | 18 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 19.05 | 4 | 19.05 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 20 | 4 | 20 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 22 | 4 | 22 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 25 | 4 | 25 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 25.40 | 4 | 25.4 | 120 | R 1/8 | 27 | 5 |
| SDA 4 120 28 | 4 | 28 | 120 | R 1/8 | 27 | 5 |
| SDA 6 065 12 | 6 | 12 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 12.7 | 6 | 12.7 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 14 | 6 | 14 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 16 | 6 | 16 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 18 | 6 | 18 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 19.05 | 6 | 19.05 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 20 | 6 | 20 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 22 | 6 | 22 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 25 | 6 | 25 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 25.4 | 6 | 25.4 | 65 | R 1/8 | 27 | 5 |
| SDA 6 065 28 | 6 | 28 | 65 | R 1/8 | 27 | 5 |
| SDA 6 100 12 | 6 | 12 | 100 | R 1/8 | 27 | 5 |
| SDA 6 120 12.7 | 6 | 12.7 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 14 | 6 | 14 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 16 | 6 | 16 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 18 | 6 | 18 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 19.05 | 6 | 19.05 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 20 | 6 | 20 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 22 | 6 | 22 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 25 | 6 | 25 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 25.40 | 6 | 25.40 | 120 | R 1/8 | 27 | 5 |
| SDA 6 120 28 | 6 | 28 | 120 | R 1/8 | 27 | 5 |
| SDA 8 070 14 | 8 | 14 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 16 | 8 | 16 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 19.05 | 8 | 19.05 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 20 | 8 | 20 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 22 | 8 | 22 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 25 | 8 | 25 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 25.40 | 8 | 25.4 | 70 | R 1/8 | 27 | 5 |
| SDA 8 070 28 | 8 | 28 | 70 | R 1/8 | 27 | 5 |
| SDA 8 100 14 | 8 | 14 | 100 | R 1/8 | 27 | 5 |
| SDA 8 120 16 | 8 | 16 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 18 | 8 | 18 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 19.05 | 8 | 19.05 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 20 | 8 | 20 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 22 | 8 | 22 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 25 | 8 | 25 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 25.40 | 8 | 25.4 | 120 | R 1/8 | 27 | 5 |
| SDA 8 120 28 | 8 | 28 | 120 | R 1/8 | 27 | 5 |
| 型号 | d0 | d1 | lg | g | l1 | l2 |
|---|
